Mixer Mounts or Mounting Options For Industrial Mixing applications

Quality Mounting Options

Since mount selection is largely driven by tank configuration and mixing environment, providing a highly configurable selection of mounting options is a priority at Dynamix. From our sturdy portable mixer clamp mount, to our industrial heavy-duty pedestal mounts, or our innovative drop flange mount, our engineers select the best mount mixers for your application.

Every line of Dynamix mixers provides a variety of mounting options for optimized engineering and quality results. Our mounts are available in a wide variety of configurations with light to heavy-duty construction, providing flexibility in adapting to your tank.

Mounting options for tank mixers

NMX Series Heavy-Duty Industrial Agitators

Plate Mount Option - Industrial Mixer

A standard plate for portable mixers and large industrial agitators, to mount on beams over open-head tanks.

Industrial Mixing - Flange Mount

Flange Mount Option - Industrial Mixer

Standard ANSI pipe flange for portable mixers and large industrial agitators, to mount on closed-head tanks. This mount is for non-pressurized tanks.

Drop Flange Mount Option

The drop-flange mount for portable mixers and large industrial agitators allows the shaft and drive sections to be separated, so that the shaft rests on the flange and the gearbox can be removed for service.

Industrial Mixing - Pedestal Flange Mount

Pedestal Flange Mount Option

The pedestal flange mount for portable mixers and large industrial agitators. The pedestal houses the stuffing box or mechanical seals for pressurized tanks.

Industrial Mixing - Side Mount

Side-Entry Flange Mount Option

The flange mount for portable mixers and large industrial side-entry tank agitators.

Heavy-Duty Clamp Mount Option

The heavy-duty clamp mount for portable mixers is keyed for secure positioning through 30 degrees on the horizontal axis, allowing maximum flexibility.

Mounting Options for Drum Mixers

Drum Clamp Mount

The standard clamp mount design for mixing in both open head drums. The clamp mount is angle mounted to allow for larger diameter collapsible impellers.

Industrial Mixing - Drum Lid Mount

Drum Lid Mount Option

The standard steel drum lid design mounts on a drum or barrel, with either Center Mount for solid suspension and high viscosity applications, or Offset Mount to enable the baffling effect.

Industrial Mixing - Bung Mount

Bung Hole Mount Option

The standard 2″ NPT bung port mount allows for fully enclosed mixing. Collapsible impellers expand internally to provide increased mixing in closed head drums and totes.

Mounting Options for DMx Mixers

Heavy Duty Clamp Mount

The heavy-duty clamp mount for portable mixers is keyed for secure positioning through 30 degrees on the horizontal axis, allowing maximum flexibility.

Plate Mount

A standard plate for portable mixers to mount on beams over open-head tanks.

Flange Mount

Standard ANSI pipe flange for portable mixers to mount on closed-head tanks. This mount is for non-pressurized tanks.
